2200/2300 Series Small Modular Belt Conveyors - General Specifications
- Flat Belt End Drive, Flat Belt Center Drive, and iDrive models
- 1.5" (38mm) pitch diameter head and tail pulleys
- 4" (102mm) - 24" (610mm) widths
- 1.5' (457mm) - 30' (9,144mm) lengths
- Loads up to 150 lbs (68 kg)
- CE Models Available
Small Belt Conveyor Applications:
- Small Part Transfers
- Part Accumulation
- Small Part Handling
- Part/Package Infeed and Outfeed
- Automated and Manual Assembly
