5200 Series Conveyors

 5200 Series Conveyors



5200 Series End Drive
5200 Cleated Conveyors



5200 Series Conveyor Systems: Feature Overview

  • QWIK slots make mounting controls and accessories simple
  • Easy frame reconfiguration with no drilling required
  • Patented sprocket alignment key for quick belt alignment
  • Completely contained belt reduces pinch points
  • Nose bar option for small parts transfer


5200 Series Conveyors: General Specifications

  • Extruded Aluminum Frame
  • Straight Flat Modular Plastic Belt and Cleated Modular Plastic Belt models
  • Conveyor Widths
    • Straights: 8" (203 mm) - 60" (1524 mm) in 2" increments
  • Lengths: 36" (914mm) - 999" (25,375 mm)
  • Load Capacity
    • Straights: up to 1000 lbs. (453 kg)
  • CE Models Available


5200 Series Conveyor Applications:

  • Automated Assembly
  • Packaging
  • Accumulation
  • Print/Labeling/Marking
  • Sortation
  • Testing and Inspection
  • Curing, Cooling, Heating and Cleaning
