2300 Series Small Conveyor: Feature Overview
- SmartSlot™ mounting system fr attachments without the drawback of T-slots that collect dust
- Quick five-minute belt change
- Rack and pinion belt tensioning for fast, accurate single-point belt tensioning
- V-groove bed plate with guided belt provides positive belt tracking, even under demanding side load applications
- Non V-guided belts use our patented belt tracking cams, offering you the widest belt selection possible
- 50% more belt take-up extends conveyor belt life
2300 Series Small Conveyor - General Specifications
- Flat Belt End Drive, Flat Belt Center Drive and Cleated Belt End Drive models
- 1.25" (32 mm) diameter drive and idler pulleys turn approximately 4.2” (107 mm) of belt per revolution
- 1.75" (44 mm) - 24" (610 mm) widths
- 18" (457 mm) - 24' (7,315 mm) lengths
- Loads up to 120 lbs* (54 kg)
- Models Available
