5300 Series DustPruf Conveyors

 5300 Series Conveyors



5300 Series End Drive
5300 Series Cleated Belt
5300 Series Curved
5300 Series Z-Frame
5300 Series Z-Frame Cleated  5300 Series Z-Frame Curved

5300 Series Modular Belt Conveyors: Feature Overview

  • Modular 15° curve segments and side rail design make reconfiguration quick and easy
  • QWIK slots make mounting controls and accessories simple
  • Easy frame reconfiguration with no drilling required
  • Patented sprocket alignment key for quick belt alignment
  • Completely contained belt reduces pinch points
  • Nose bar option for small parts transfer

5300 Series Modular Belt Conveyors General Specifications

  • Extruded Aluminum Frame
  • Straight Flat Modular Flat Belt and Cleated Modular Flat Belt models
  • Curved Modular Flat Belt models
  • Conveyor Widths
    • Curves: 8" (203 mm) - 36" (914 mm) in 2" increments
    • Straights: 6" (152 mm) - 60" (1524 mm) in 2" increments
  • Lengths: 36" (914mm) - 999" (25,375 mm) lengths
  • Load Capacity
    • Straights: up to 1000 lbs. (453 kg)
    • Curves: up to 500 lbs. (226 kg)
  • Models Available

5300 Series Modular Belt Conveyors Applications:

  • Part Transfers
  • Part Accumulation
  • Mainline Packaging
  • High Speed Long Runs
  • Automated and Manual Assembly
